| OS | Android 12 |
| CPU | Rockchip RK3588 (Octa Core; 2.4GHz)
Cortex-A76×4 @2.4GHz, Cortex-A55×4 @1.8GHz |
| GPU | ARM Mali G610 |
| RAM/ROM | 8GB/256GB，16GB/256GB
8GB/512GB, 16GB/512GB Optional |
| LCD | 10.1 inch; 1200×1920; 450nits
IPS Screen; 1000nits(1200×1920) Optional |
| Touch Screen | 10 Point Touch
Stylus Support; Wet Hand Touch Support |
| Camera | Front: 5MP; Rear: 13MP (Flash light) |
| Power and Battery | 6000mAh / 7.6Vdc (45.6Wh)
Charging time: about 4 hours
Usage time: 8H30min (50% volume, 60% brightness, playing local 1080P video)
Standby time: about 43 days (screen off standby) |
| WWAN | FDD_LTE: B1/B2/B3/B4/B5/B7/B8/B28/B66
TDD_LTE: B40
WCDMA: B1/B2/B4/B5/B8
GSM: 850/900/1800/1900
Module: SLM770A |
| GPS | BDS, GPS, GLONASS |
| WIFI | 802.11a/b/g/n/ac/ax Wireless Internet; Wireless AP (Mobile AP); 2.4G, 5G; Support WiFi6
WiFi/Bluetooth 2-in-1 |
| BLUETOOTH | 5.0 Version |
| NFC | 13.56 MHz, Distance: 1-3cm; ISO/IEC 14443A/B; ISO/IEC 15693 |
| MIC | Sensitivity: -32±2d; Output Impedance: 2.2kΩx1 |
| SPEAKER | 8Ω 1.5 Watt |
| Sensor | Light sensor, Magnetic sensor, Pressure sensor, G-sensor, Distance sensor, Acceleration sensor, Gyroscope, Motor |
| Size | 268.9×176.8×18mm |
| Weight | 1150±50g |
| Language | Multi language |
| Interface In/Out Port | Type-C *1 (OTG); SIM Card Slot*1; TF Card Slot*1; Earphone*1; DC*1 (4.0×15mm); USB-A：USB 2.0 *1+USB 3.0 *1; RJ45*1; RS232*1; HDMI*1
Bottom pogopin: USB 2.0; Charging; RS232
Back pogopin: USB 2.0; RS232 |
| Button | V+ -, Power, "F" for Barcode Scan
Customized Button: P,H (Default No Functionality) |
| 1D/2D Barcode | Optional: Honeywell N4680 Optional |
| UHF RFID | M-500 Optional
American standard M-500 (902Mhz – 928Mhz): External (3-5M)
European standard M-500 (865MHz – 868MHz): External (3-5M)
M-301 Optional
American standard M-301 (902Mhz – 928Mhz): External (5-8M)
European standard M-301 (865MHz – 868MHz): External (5-8M) |
| Fingerprint | Optional: AFM60 Optional |
| Accessories | Blue Box; DC Charger (12V 4A); Carry strap; Screw; Wrist strap; Screwdriver
Optional: Docking Station; Car Holder STA15; Car Holder STA03; Type-C 65W fast charging charger; Magnetic Keyboard |
| Multi-Media (Hardware Decoding) | Photo Viewer: BMP, JPG, GIF, PNG
Video Format: MEPG 1/2/4, H.263/H.264, RMVB, WMV/VC-1, MVC, AVS, MJPEG (UP TO 1080P)
Audio Format: MP3, WMA, WAV, OGG, FLAC, ALAC, APE, AAC, AC-3, DTS (need license) |
| Proof Degree | IP65 Anti-dust & Waterproof, 1.2m Dropping Resistance |
| Certification | MIL-STD-810G; CE, FCC, 3C |
| Temperature | Storage Temperature: -40°C to 60°C; Operation Temperature: -20°C to 55°C |
