| OS | Windows 11 Pro |
| CPU | Intel I5-1235U (10 cores, 12 threads; 1.3GHz/4.4GHz, 15W)
I7-1255U Optional (10 cores, 12 threads; 1.7GHz/4.7GHz, 15W) |
| GPU | Intel® Iris® Xe Graphics 80EU
I7: Intel® Iris® Xe Graphics 96EU |
| TPM | Support TPM2.0 |
| RAM/ROM | I5：RAM 8GB/16GB (Max 64GB); ROM 128GB/256GB/512GB
I7：RAM 16GB/32GB (Max 64GB); ROM 128GB/256GB/512GB
RAM: LPDDR5 496 Ball; ROM: M.2 2242 SATA (C500) |
| LCD | 10.1 inch; 1200×1920; 450nits |
| Touch Screen | 10 Point Touch
Stylus Support; Wet Hand Touch Support |
| Camera | Front: 5MP; Rear: 8MP |
| Power | 6000mAh, 7.6V lithium battery (45.6Wh)
Charging time: 2H30min; Usage time: 5H30min (50% volume, 60% brightness, local 1080P video); Standby: ~6 days
DC4.0, 12V DC input; Supports Type-C 65W fast charging |
| WWAN | FDD_LTE: B1/B2/B3/B4/B5/B7/B8/B28; TDD_LTE: B40; WCDMA: B1/B2/B4/B5/B8; GSM: B2/B3/B5/B8
Module: SLM770A (EC25-AUX in North America) |
| GPS | BDS, GPS, GLONASS |
| WIFI | 802.11a/b/g/n/ac/ax Wireless Internet; Wireless AP (Mobile AP); 2.4G, 5G
Intel® Wi-Fi 6 AX201 (WiFi/Bluetooth 2-in-1) |
| BLUETOOTH | 5.2 Version |
| NFC | 13.56 MHz, Distance: 1-3cm; ISO14443 TYPE A |
| MIC | Sensitivity: -32±2d; Output Impedance: 2.2kΩx1 |
| SPEAKER | 8Ω 1.5 Watt |
| Sensor | Light Sensor, Acceleration Sensor, G-Sensor |
| Size | 268.9×176.8×18mm |
| Weight | 1190±50g |
| Language | Multi language |
| Interface In/Out Port | DC*1 (4.0×15mm); HDMI Type A x1; USB Type_A: USB3.2 Gen1 x2; USB Type_C: USB3.2 Gen1 x1 (PD/DP/Data/Charging); Earphone: ∮3.5mm x1; RJ45 (Gigabit); RS232 (DB9)
Bottom pogopin: USB 2.0; Charging; RS232
Back pogopin: USB 2.0; RS232 |
| Button | V+ -, Power, "F" for Barcode Scan
Customized Button: P, H (Default No Functionality) |
| 1D/2D Barcode | Optional: Honeywell N4680 Optional |
| UHF RFID | M-500 Optional
American standard M-500 (902Mhz – 928Mhz): External (3-5M)
European standard M-500 (865MHz – 868MHz): External (3-5M)
M-301 Optional
American standard M-301 (902Mhz – 928Mhz): External (5-8M)
European standard M-301 (865MHz – 868MHz): External (5-8M) |
| Fingerprint | Optional: AFM60 Optional |
| High Precision GPS | Optional: UM960 |
| Accessories | Blue Box; DC Charger (12V 4A); Carry strap; Screw; Wrist strap; Screwdriver
Optional: Docking Station; Car Holder STA15; Car Holder STA03 |
| Multi-Media (Hardware Decoding) | Photo Viewer: BMP, JPG, GIF, PNG
Video Format: MEPG 1/2/4, H.263/H.264, RMVB, WMV/VC-1, MVC, AVS, MJPEG (UP TO 1080P)
Audio Format: MP3, WMA, WAV, OGG, FLAC, ALAC, APE, AAC, AC-3, DTS (need license) |
| Proof Degree | IP54 Anti-dust & Waterproof, 1.2m Dropping Resistance |
| Certification | MIL-STD-810G; CE, FCC, 3C |
| Temperature | Storage Temperature: -40°C to 60°C; Operation Temperature: -20°C to 55°C |
